ZF grearbox original spare parts serves good
How to dessemble and repair the ZF 4WG200 gearbox and maintence it well
ZF 4wg200 gearbox is the product of ZF, a German transmission system supplier. It adopts electro-hydraulic control and fixed shaft power shift gearbox.
The gears are the first four and the last three, and the supporting engine power is about 200kW. It is commonly used for 5-ton and 6-ton loaders.
Liugong wheel loader gearbox aseemble :
BS305
ZF 4WG158
ZF 4WG200
ZF 4WG250
ZF 4WG308
| PART NUMBER | DESCRIPTION |
| 5228131 | SEAT |
| Z3A00404400 | SEAT SUPPORT |
| W370000580B | SHIFT LEVER |
| JB331426500 | PUMP P-TRANSMISSION |
| 2W8002+C | PUMP GP-WATER |
| W066600000 | GEAR PUMP |
| W066500000 | GEAR PUMP |
| W064100000 | GEAR PUMP CBGJ3125 |
| W068000000B | GEAR PUMP (97+83 CCW) |
| W057700100B | SEAL KIT STEERING CYLINDER |
| W051500090 | SEAL KIT LIFTING CYLINDER |
| W051300100B | SEAL KIT TILTING CYLINDER |
| W090900000A | AMPLIFICATION STEERING GEA |
| PLC SIEMENS S7 200 6ES7 214-2AD23-OXBO | |
| Item | N° Parts | Description | |
| 1 | W030600009 | 6009 054 155 | CONTROL UNIT |
| 2 | W030600011 | 0501 313 375 | SOLENOID VALVE (BOSCH) |
| 3 | 0501 313 375 | SOLENOID VALVE (CHINESE) | |
| 4 | W030601610 | 0730 150 759 | THRUST WASHER |
| 5 | W030600690 | 0501 208 765 | GEAR PUMP |
| 6 | W030601870 | 0730 150 779 | THRUST WASHER |
| 7 | W030602010 | 0501 309 330 | OUTER CLUTCH DISC |
| 8 | W030600020 | 0899 005 051 | CONVERTER |
| 9 | W030602020 | 4644 308 329 | INNER CLUTCH DISC |
| 10 | Seal Kit for complete Gear Box ZF | ||
| 11 | W030602060 | 4644 252 089 | SPUR GEAR Z=56/22 |
| 12 | w030602320 | 0501 309 329 | OUTER CLUTCH DISC |
| 13 | W030601650 | 0730 150 773 | THRUST WASHER |
| 14 | 0730 150 777 | THRUST WASHER | |
| 15 | W030601660 | 0750 119 100 | SET OF POLINES |
| 16 | W030600120 | 4466 351 081 | CAP |
| 17 | W030600600 | 4642 301 136 | BEARING COVER |
| 18 | W030601720 | 4642 308 555 | THRUST WASHER |
| 19 | W030601710 | 4645 351 094 | THRUST WASHER |
| 20 | W030601090 | 4644 303 389 | OUTOUT FLANGE |
| 21 | W030601510 | 0730 003 504 | SHIM S=1.0 |
| 22 | W030601520 | 0730 003 505 | SHIM S=1.2 |
| 23 | W030601530 | 0730 003 506 | SHIM S=1.4 |
| 24 | W030601540 | 0730 003 507 | SHIM S=1.6 |
| 25 | W030601560 | 0730 003 509 | SHIM S=2.0 |
| 26 | W030602860 | 4644 306 558 | VALVE BLOCK |
| 27 | W110014009 | TEMP SENSOR | |
| 28 | W01420240 | PRIMING PUMP S305A | |
| 29 | W030600600 | 4642 301 136 | BEARING COVER |
| 30 | W030601640 | 4644 308 265 | THRUST WASHER |
| 31 | W030601730 | 0750 112 140 | SEALING RING |
| 32 | W030602150 | 0750 112 141 | SEALING RING |
| 33 | W030602360 | 4642 308 332 | INNER CLUTCH DISC |
